Pressure Sensor Metal Bellows

Pressure Sensor Metal Bellows are flexible metal elements used in pressure measurement and control devices. The corrugated structure converts changes in medium pressure into axial movement or elastic deformation. This mechanical response can then support a transmission mechanism, switch action, or signal conversion inside the instrument.

Available materials include stainless steel, nickel, and alloy materials. The product can be designed as a single-ply structure, a multi-ply structure, or a precision bellows assembly. Its outside diameter, overall length, connection position, and end structure can be customized according to the internal layout of the sensor.

This design is suitable for compact, small-size, and non-standard measuring components where the bellows must fit a defined installation space and provide a controlled mechanical output.

Product selection should focus on the relationship between the pressure range, effective area, and elastic deformation. The effective area is designed according to the required measurement range. Wall thickness and effective convolutions are then determined according to sensitivity, output displacement, and structural stability.

A different effective area can produce a different mechanical force under the same pressure condition. At the same time, wall thickness, corrugation profile, and number of convolutions affect the response and axial movement of the component.

For pressure switches, the bellows structure can be designed according to the travel required by the triggering mechanism. For differential-pressure devices or instrument control systems, the pressure conditions on both sides, installation direction, and connection dimensions should be confirmed.

For industrial automation equipment, the operating temperature, medium, and expected operating cycles should also be provided. Final performance must be based on the approved drawing, confirmed technical conditions, and agreed inspection requirements.

Yixing Blog Pipeline Equipment Co., Ltd. develops and manufactures metal bellows and non-standard assemblies. The technical team can work from a sensor assembly drawing, existing sample, or prototype.

During technical review, the team can confirm the measurement range, effective area, required sensitivity, available installation space, and end connection. When the bellows needs to work with a connection seat or transmission component, related parts can be combined into a complete assembly. This can reduce additional welding and dimensional adjustment by the purchaser.

Manufacturing capabilities include metal forming, automatic longitudinal seam welding, argon arc welding, laser cutting, and component assembly.

Inspection covers raw material cutting, forming, welding, assembly, and finished-product acceptance. Every product is inspected before packaging, and customer-arranged third-party inspection is supported.

The Pressure Sensor Metal Bellows is suitable for pressure sensors, pressure switches, differential-pressure devices, instrument control systems, and industrial automation equipment.

OEM and ODM production is available. Products can be manufactured according to technical drawings or prototypes. The minimum order quantity is one piece, and a sample can be arranged before batch production.

Custom sample development generally requires about six months. Customized product production normally requires two to three months. One standard specification generally requires about one month, while special materials, larger quantities, or projects requiring tooling normally need two to three months.

Production photos or videos can be provided. Products can be packed in small packages or wooden cases. EXW and FOB delivery terms are supported. A six-month industry warranty is provided, with technical assistance available by phone, online communication, or on-site support.
